Drilling holes in cable tray shafts

Drilling holes in cable tray shafts should be done carefully using proper tools, placement, and safety measures to maintain structural integrity and comply with standards.Tools and SafetyWhen drilling holes in metal cable trays, use band saws, circular saws, or angle grinders with blades suitable for the tray material (e.g., stainless steel or carbon steel) to avoid damage or contamination . Always wear Kevlar gloves, eye protection, and other PPE to prevent injury from sharp edges or metal swarf . Avoid using cutting torches, as they can weaken the material and damage surface treatments .Hole Placement and SizeField drilling is typically done at the bottom or sides of the tray to allow cable exit or attachment of brackets .Standard practice includes drilling 7/16” holes in solid bottoms 1” from the inside edge for mounting hangers, and 5/16” or 3/8” holes for dropouts or pivot connectors .Maintain adequate spacing between holes to preserve tray strength and avoid compromising load-bearing capacity .For perforated trays, consider hole geometry to minimize electromagnetic interference (crosstalk) between power and signal cables, especially in sensitive installations like offshore plants .Installation ConsiderationsEnsure the tray remains accessible and avoid installing in areas prone to physical damage .Use mounting slots and brackets to secure components without overloading the tray .Follow industry standards such as BS EN 61537, BS 6946, NEC, NEMA, and IEC for safe installation and structural support .Avoid cutting structural building members to accommodate trays, and do not mix cutting blades between different metals to prevent galvanic corrosion .Best PracticesDrill holes only where necessary for cable routing or mounting.Remove any burrs after drilling to prevent cable damage .Plan hole placement in advance to maintain tray integrity and compliance with electrical and safety standards .For offshore or high-voltage installations, consider shielding and crosstalk effects when determining hole size and pattern .By following these guidelines, you can safely drill holes in cable tray shafts while maintaining structural integrity, ensuring proper cable support, and complying with relevant standards.
